PVC exterior panel door Trocal 88 Standard
TROCAL 88 PVC-U residential door – The most advanced door programme
- Excellent heat insulation thanks to multi-chamber
- Narrow face width for more light
- High load capacity
- Lead-free profiles, completely recyclable
Insulation
Ud from 0,74 W/m²K
Chamber system
6 chambers
Building depth
88 mm
€ 1490 , - /Stk. € 1752 , 94 /Stk.
1 wing door 1000/2100mm
*Beachten Sie unseren QUANTITY DISCOUNT
Direkt vom Hersteller
FENSTERNORM - manufacturer and deliverer of windows and doors of high-quality Trocal and Schüco profiles.
Technical details
TROCAL 88 PVC-U residential door - datasheet
- Building depth 88 mm, face width 183 mm
- Ud-value 0,74 W/m²K
- Standard version - thermal inset filling 40 mm
- Laminated safety glass
- Enhanced insulation zone with foam filling
- Inwards outdoors opening available only
- DORMA door closers on request
- Barrier-free and thermally-separated thresholds
- 3D adjustable hinges that are secured from inside
- Easy-to-integrate comfort and security functions
- Force-fitting welded synthetic corner connectors
- A triple locking system with two hooks and a single deadbolt
- A wide range of construction forms and sheet constructions
- Alarm contact and e-opener optional
PVC exterior panel door Trocal 88 Standard Modelle
Construction forms preview
Product features
Door profiles of a market leader
Schüco makes windows and doors from the profile TROCAL - a worldwide accepted market Leader in the field of PVC. Already in the middle of the 1950s the company had inspired its customers with extraordinary windows of PVC. FENSTERNORM produces windows and doors from the profile Trocal 88 AluClip which are produced with a successful with high-quality product from the world-renowned market leader in the field of PVC windows. These innovative, extremely solid and easy-to-care for windows were received enthusiastically by customers. PVC windows and doors became best sellers and remained such in the 21st century. Since the beginning of production, the PVC-windows they were continually optimized in order to improve heat insulation, noise and burglary protection and driving rain impermeability.
Perfect appearance and stability
The aluminium PVC house door supplements the window systems TROCAL and this provides the entire facade with a harmonious look. The house door consists of two cover layers which are stuck together through vacuum processing and foam filling between them. The outer shells consist of powder-coated aluminium and guarantees high weather resistance. The combination of PVC and aluminium ensures longevity and meets the highest quality standards. The covering layers consist of ABS. These are acrylic surfaces which are UV-stabilised and extremely scratch resistant.
Doors made entirely of PVC are mostly used as secondary entrance doors. For higher demands and enormous strain, we recommend our premium aluminium profiles.
Greenline technology
Reduction of energy use and emissions are among the key challenges of our time. There are strict laws for energy efficiency. That's why many owners exchange their windows and doors in order to optimise insulation. The demands on environmental compatibility and sustainability are also valid for TROCAL. To produce PVC profiles, we use lead-free calcium-zinc based stabilisers (greenline).
Product benefits at a glance
- The innovative multi-chamber profile TROCAL 88 Standard has excellent heat insulation qualities and offers the necessary insulating door feelings and functional glazing. The thermally-separated threshold is made up of aluminium on the outside and PVC on the inside. It prevents condensation water formation and is suitable for people with disabilities.
- Barrier-free living: The threshold system TROCAL 88 Standard consists of two real sealing levels and it is maximum 20 mm high. The system is completely thermal insulated and prevents condensed water formation.
- Stability and security in every detail: Stability through perfect pressurised reinforcements profiles and welded corner connectors. The demands with regards to anti-burglar protection can be fulfilled individually.
Optional accessories
Even the standard version of TROCAL 88 AluClip meets the needs of both aesthetically and quality-oriented customers. Optionally you can upgrade your door with the following accessories:
- Alarm contacts with a magnetic switch for more security;
- An anti-panic fitting for fast opening in case of emergency, executed with a crossbar;
- Door closer from Dorma in white and grey for a smooth and delayed closure of heavy doors;
- Step protection sheet against scratches and bulges;
- A peephole with a wide ring lens for increased security;
- A domestic animal flap, integrated into the panel or the glass according to your wishes;
- An E-Opener (electric door-opener) opens a door at the touch of a button so you don’t need to open it personally. The electrical connection is made by the customer or by a technician.
Service from FENSTERNORM
FENSTERNORM doesn't have a modern machinery park but it's rather proud of its skilled technicians with many years of experience. The PVC house doors TROCAL 88 Standard are produced and delivered within a very short time. Upon enquiry, we will take over the transportation, the on-site assembly and will completely clean everything in accordance with valid building standards. Our team is happy to contact you and is ready to answer your questions.
