In window construction, hardware refers to the components that enable the window to be opened and closed. It therefore comprises the locking mechanism on the opening side of the window sash and the corresponding keeps in the frame, as well as the hinges on the opposite side of the window sash. All of the mechanics that allow a window sash to be opened, and in the case of a tilt-and-turn window to be turned or tilted, are also part of the hardware. In professional terminology, the window handle used to operate the hardware is not counted as part of the hardware itself, but is often also "meant" when hardware is spoken of.

There are six resistance classes with increasing protective effect from RC1N to RC6 in accordance with the European standard DIN EN 1627 (the old designation, used until September 2011, was WK 1 to WK 6). RC stands for Resistance Class.

RC1N - Attempted break-in using physical force such as kicking, body-slamming, jumping against, levering up and the like. Elements of this resistance class are therefore mainly suitable as protection against vandalism. Windows of resistance class 1 offer only very low burglary protection.

RC2 - The opportunist offender additionally attempts to force the window open using simple tools such as a screwdriver, pliers or wedges. Windows of resistance class 2 offer low to average burglary protection.

RC3 - The offender additionally attempts to gain entry using a second screwdriver and/or a crowbar. WK3 windows offer high burglary protection. In a private household, protection to resistance class RC 2 and RC 3 is usually sufficient.

RC4 - The experienced offender additionally uses sawing and striking tools, e.g. an axe, crowbar, hammer and chisel, as well as a cordless drill. Windows of resistance class 4 offer very high burglary protection.

RC5 - The very experienced offender additionally deploys power tools, e.g. a drill, jigsaw or reciprocating saw and an angle grinder with a maximum disc diameter of 125 mm. Windows of resistance class 5 offer very, very high burglary protection. The resistance time is at least 15 minutes.

RC6 - The very experienced offender additionally uses power tools such as a drill, jigsaw or reciprocating saw and an angle grinder with a maximum disc diameter of 230 mm. Windows of resistance class 6 offer extremely high burglary protection, and the resistance time is at least 20 minutes.

A RAL colour refers to standardised colours from a colour collection that has been authoritative for colour selection for over 85 years and is distributed by RAL GmbH under the name RAL Classic.

Each colour in the colour catalogue is assigned a four-digit colour number. The first digit is systematic: 1 - yellow, 2 - orange, 3 - red, 4 - violet, 5 - blue, 6 - green, 7 - grey, 8 - brown, 9 - white/black shades, and the remaining three digits are chosen sequentially.

For a surcharge, almost all products, such as timber windows, timber-aluminium windows, aluminium windows, roller shutters and external window sills, can be produced in a RAL colour of your choice.

Originally, only small panes of glass could be manufactured, and glazing bars served as dividers. Nowadays, glazing bars are used predominantly for aesthetic reasons.

A distinction is made between three different types:

Genuine or glass-dividing bars

This refers to a type of bar that divides the glass, so that each bar field is fitted with an individual pane. Windows made up of several small panes are rarely found these days. This method of construction closely resembles the original way of manufacturing and is therefore also very labour-intensive. In addition, heat loss is greatest with the glass-dividing bar variant. Every interruption of the pane is in direct contact with the outside of the window, and this creates a cold bridge.

Imitation or bonded-on bars

The so-called “Viennese bar” (Wiener Sprosse) is counted among the imitation glazing bars and represents the affordable alternative to genuine glazing-bar windows. This type of bar is visually indistinguishable from glass-dividing bars and is ideal for recreating slim bars. The surface-mounted bars are simply bonded onto the glass and merely sealed with silicone. For this reason, they have no effect on the insulating properties of the glazing.

This type of bar looks particularly attractive on country-style houses or restored buildings that are listed as protected monuments. They give the entire building an exceptional and historic appearance.

Internal bars

Internal bars are inserted as a bar grid inside the glazing. This eliminates the labour-intensive upkeep of the bar construction. A particular feature of bars located within the cavity between the panes is that, with triple glazing, the bar is placed in only one of the two cavities between the panes.

Today, glazing-bar windows are used predominantly in the renovation of listed buildings and, in new builds, serve more as a design feature. In doing so, they lend the window and the entire building a distinctive character.

At Fensternorm, you can choose as standard between internal bars in a width of 18 mm or 8 mm and surface-mounted bars in a width of 26 mm. Of course, we will endeavour to fulfil (almost) any other size requirement you may have.

The thermal transmittance coefficient, abbreviated U for unit of heat transfer (the unit of heat transfer), replaced the k-value in the course of European standardisation. Measuring the U-value determines the heat loss from the inside to the outside, specifically per square metre and per hour at a 1° temperature difference.

A window's thermal insulation depends on the frame material, the glazing and its airtightness. A window's insulating properties are determined by the U-value. The lower this figure, the better the thermal insulation.

For windows, three U-values are generally distinguished. The thermal transmittance coefficient Uw refers to the entire window. This value incorporates the U-values for the glazing Ug and the frame Uf.

• Uf = U frame – is the U-value of the window frame.
  The Uf-value is determined by measurement for the frame-and-sash combination. The visible width of the profile is taken as the area for calculating the Uw-value.

• Ug = U glazing – is the U-value of the glazing.
  The Ug-value depends on the type of gas filling in the cavity between the panes, the distance between the panes and the number of panes.

• Uw = U window – is the U-value of the entire window.

The thermal transmittance coefficient for windows is generally calculated for the standard window size of 1.23 m x 1.48 m. Please note that larger glass areas achieve better values, since glazing allows better U-values than the frame material.

Under OIB Guideline 6 of 2011, the Uw-value for standard glazing must not exceed 1.4 W/m2K. The German Energy Saving Ordinance (EnEV) of 2014 limits the thermal transmittance coefficient to 1.3 W/m2K for an existing building. Windows with a Uw-value no greater than 0.8 W/m2K are considered suitable for passive houses.
